Pixel size

2.8μm*2.8μm

TV Standard

AHD PAL

Resolution

 720P or 1080P optional

Synchronization system

Inner Synchronization

Vertical

sync frequency

50Hz / 60Hz

Minimum illumination

0.001Lux/F1.2

Video out

1.0vp-p, 75Ω

Gamma rate

0.45

AGC

auto

Wide dynamic range

no

Sound to

Noise Ratio

> 48dB

White balance

auto

BLC

auto

Lens

size

f=2.16mm

f=1.78mm

f=1.58mm

horizontal angle

160°

180°

200°

Diagonal angle

180°

200°

220°

IR light

no

IR-CUT

no

Audio

no

Electric current

DC12V 65mA±10%

Voltage

DC 5-16V

Operating temperature

－20°C~70°C , RH95％ MAX

Storage temperature

－30°C~80°C，RH95％ MAX

Net Weight
