AI BSD Pedestrain and Vehicle Detection Backup Camera

AI BSD camera detect outside pedestrain and vehicle via green/yellow/red range and bibibi alarm,720P/960P/1080P optional

  • Brand:

    DUUHNN
  • Item NO.:

    DH-RC05
  • Order(MOQ):

    1pcs
  • Payment:

    TT, Paypal,Western Union,MoneyGram,Alipay
  • Price:

  • Warranty:

    2Years
  • Delivery Time:

    3-8 working days for sample

Main Features:


* Built in AI BSD chipset: to detect outside pedestrain & vehicle and early warning when entering alarm frame & auto tracking;

* Via AI intelligent algorithm, when entering the blind area, it will auto beep and warn;different color frame(green/yellow/red color area) at different frequency alerts(like ralar alram), which greatly improves the safety guarantee;

* Separation mode of lens and infrared light design: to solve the phenomenon of night vision explosion and light shadow;

* Waterproof/anti-shock/anti-interference: patent appearance, novel & delicate. Especially designed for large vehicles;

* Resolution HD 720P/960P/1080P optional;

* Specially designed for vehicle environment: supports wide range of video dynamics, 3D noise reduction, automatic White balance, automatic electronic shutter, adapt to different light work, automatic AGC control, automatic brightness adaptation, clear picture quality, dynamic video, fast response, no smearing afterimage, and vivid colors;

* Using high-power infrared emission tube, the night vision 10-15 meters;

* Adopt vehicle-specific IR-CUT, anti-shock design, automatic color to black function;

* Aluminum alloy shell design:shockproof and drop-resistant, light weight, great heat dissipation, and high grade.

* Use stainless steel screws: will not rust and at high grade;

* It adopts 4-core aircraft carrier socket with self-locking function and anti-seismic

* Using submersible pump waterproof technology, truly 100% waterproof



Technical Parameter


ItemsDescription
Item NameAI BSD Rear View Camera
ModelDH-RC05
SensorHD color AHD
AI detect rangeOutside pedestrain & vehicle
AI BSD alarm color frameGreen:safe;Yellow:warn;Red:Dangous
AI early warningAuto Didi warning when entering BSD area
TV standardPAL/NTSC
Resolution1280×720(720P)/1920*960(960P)/1920*1080(1080P) optional
Auto White Balance(AWB)Auto
BLCAuto(the picture will not be exposed)
Electronic shutterAuto(adapt to different light work)
Automatic AGC ControlAuto (screen brightness adaptive
SNR48dB (automatic gain control on)
GAMMA Coefficient0.45
Video output1.0Vp-p75ohm-AHD
Minimum illumination0 lux ((LED lights turn on 8 high-power infrared lights)
Night vision distance<15 meters
Viewing angleAbout 120 degrees (other angles are optional)
Microphoneoptional
WaterproofIP69K
Power supplyDC 12V
Consumption2W
Net weight200 g
Operating temperature-20 to 70 degree
Relative humidity<93%


Application: Widely used in vehicles such as buses, muck trucks, mixer trucks, agricultural machinery, trucks, engineering vehicles, fire trucks, ships etc.
